Delta inverter ac motor driveVFD32AMS43ANSAA 3HP 15kW 480V 32A VFD-MS300 Series

Delta inverter ac motor driveVFD32AMS43ANSAA 3HP 15kW 480V 32A VFD-MS300 Series Featured Image
  • Delta inverter ac motor driveVFD32AMS43ANSAA 3HP 15kW 480V 32A VFD-MS300 Series
  • Delta inverter ac motor driveVFD32AMS43ANSAA 3HP 15kW 480V 32A VFD-MS300 Series
  • Delta inverter ac motor driveVFD32AMS43ANSAA 3HP 15kW 480V 32A VFD-MS300 Series

Short Description:

  • Series: MS-300
  • 460 V
  • 3 Phase
  • 20 HP
  • 15 KW
  • 0 – 599 Hz
  • IP 20
  • Optional EMC Filter
  • Heavy Duty Output: 32 A
  • Normal Duty Output: 36 A


We're one of the most professional FA One-stop suppliers in China.Our main products including servo motor, planetary gearbox, inverter and PLC, HMI.Brands including Panasonic, Mitsubishi, Yaskawa, Delta, TECO, Sanyo Denki ,Scheider, Siemens , Omron and etc.; Shipping time: Within 3-5 working days after getting the payment. Payment way: T/T, L/C, PayPal, West Union, Alipay, Wechat and so on

Whatsapp

Product Detail

Product Tags

Spec Detail

PRODUCT SPECIFICATIONS

Model Name VFD32AMS43ANSAA
Series MS-300 Series
Input Voltage – Phase 460 V – 3 Phase
Motor Power Range 20 HP – 15 KW
Frequency 0 – 599 Hz
Frame Size E1
IP Level IP 20
EMC Filter Optional
Normal Duty* Amps 36 A
Heavy Duty** Amps : 32 A
Weight 8.75 Lbs
Dimensions 5.12 (in) x 9.84 (in) x 7.83 (in)

* Normal duty: rated current 120% for 60 seconds; 150% for 3 seconds
** Heavy duty: rated current 150% for 60 seconds; 200% for 3 seconds

FLUID_M

Fluid Automation Systems

Fluid automation systems are mainly applied for controlling the complex processes of air-conditioning systems, air compressors, and water treatment plants. Replacing manual process management with an automated system achieves efficient and stable operations with distributed processing capabilities, constant control, and central monitoring.

Delta is dedicated in developing reliable and optimized automation products, such as PLCs, AC motor drives, servo drives and motors, HMIs, and temperature controllers. For high-end applications, Delta presents mid-range PLCs with excellent algorithms and stability. Adopting a modular design with various extension modules for system scalability, Delta’s mid-range PLC features integrated PLC programming software and an operation interface with multiple function blocks (FB). Delta also offers a variety of industrial Ethernet switches to connect different industrial networks for precise process monitoring. The highly efficient, stable, and reliable automation systems meet the requirements for a wide range of fluid system applications.

Textiles

Delta offers an energy-saving, high-speed, automated and digitized solution for cotton spinning equipment. To fulfill industry demands for tension control, simultaneous control, and high-speed precision operation, Delta’s solution adopts encoders for precise positioning, and AC motor drives and PG cards for motor driving with the PLC as master control. Users are able to set the parameters, control the temperature, and monitor the process via the HMI. The solution can be widely applied to mercerizing machines, dyeing machines, rinsing machines, jig dyeing machines, tentering machines, and printing machines.

Delta’s Textile Vector Control Drive CT2000 Series features specific wall-through installation and fan-less design for robust protection against cottons, dust, pollution and instant voltage fluctuation under harsh environments. It is suitable for spinning frames and roving frames in the textile industry, and can also be applied for machine tools, ceramics and glass manufacturing.
