Spec Detail
Specifications
| Range | Enerlin'X |
|---|---|
| Product name | Link |
| Product or Component Type | Gateway |
| device short name | Link150 |
| Device Application | Gateway |
| external supply | External supply 19.2...26.4 V DC, <500 mA |
| PoE | Power supply device PoE IEEE 802.3af |
| Number of port | 2 |
| communication gateway | Ethernet/fieldbus |
| Current consumption | 130 mA 24 V DC via external supply 20 °C) 65 mA 48 V DC via PoE 20 °C) |
|---|---|
| Maximum power consumption | 15 W via PoE |
| Communication network type | Ethernet, Ethernet Modbus TCP/IP daisy chain even/odd or none 10/100 Mbit/s Ethernet, PoE 15W (Power over Ethernet) even/odd or none 10/100 Mbit/s Ethernet, FTP even/odd or none 10/100 Mbit/s Ethernet, HTTP even/odd or none 10/100 Mbit/s Ethernet, SNMP even/odd or none 10/100 Mbit/s Ethernet, Modbus TCP/IP even/odd or none 10/100 Mbit/s RS232, Modbus RTU, JBUS, PowerLogic (SY/MAX) even/odd or none 2400, 4800, 9600, 19200 or 38400 bauds RS232, Modbus ASCII even/odd or none 2400, 4800, 9600, 19200, 38400, 56000 or 57600 bauds RS232, Modbus Serial line slave even/odd or none 2400, 4800, 9600, 19200 or 38400 bauds RS485, Modbus RTU, JBUS, PowerLogic (SY/MAX) even/odd or none 2400, 4800, 9600, 19200 or 38400 bauds RS485, Modbus ASCII even/odd or none 2400, 4800, 9600, 19200 or 38400 bauds RS485, Modbus Serial line slave even/odd or none 2400, 4800, 9600, 19200 or 38400 bauds |
| Parity | Even/odd or none |
| Communication port protocol | Ethernet Modbus TCP/IP daisy chain 6 kV Modbus TCP/IP 6 kV Modbus RTU, JBUS, PowerLogic (SY/MAX), master - 2 or 4 wires 2.5 kV Modbus ASCII, master - 2 or 4 wires 2.5 kV Modbus RTU and ASCII, slave - 2 or 4 wires 2.5 kV |
| Communication port support | RJ45 ETHERNET RJ45 RS232 RJ45 RS485 |
| Number of inputs | 0 |
| Number of Outputs | 0 |
| Connections - terminals | Power supply screw terminal block top) 0.00…0.00 in² (0.2…1.5 mm²) rigid Power supply screw terminal block top) 0.00…0.00 in² (0.2…1.5 mm²) flexible with cable end Power supply screw terminal block top) 0.00…0.00 in² (0.2…1.5 mm²) flexible without cable end |
| Tightening torque | Power supply 2.66 lbf.in (0.3 N.m) flat 0.12 in (3 mm) |
| Wire stripping length | Power supply: 0.28 in (7 mm) for top connector connection |
| Mounting Mode | Clip-on |
| Mounting Support | 35 mm DIN rail |
| Product Certifications | cULus FCC Class A CE RCM UL cUL |
| standards | IEC 60950-1 UL 61010-2-201 UL 61010-1 CSA C22.2 No 60950-1 AS/NZS 60950-1 UL 60950-1 IEC 61000-6-2 |
| Depth | 2.83 in (72 mm) |
| Height | 4.13 in (105 mm) |
| Width | 2.80 in (71 mm) |
| Net Weight | 6.17 oz (175 g) |
| Web services | Web server |
| Local signalling | LED:Ethernet activity (ETH1) LED:Ethernet activity (ETH2) LED:module status LED:network communication status (Net Status) LED:communication RS232) LED:communication RS485) |
